LARGER SIZED PARTS

VMC 6030B-II and VMC 8030B-II

  • Two spindle configurations
  • Quad box way “Y” axis support structure
  • Full way contact at full stroke
6030/8030 models can be configured with a CAT50 6000 RPM spindle with a two speed transmission. Both models offer a 10,000 RPM CAT 40 dual belt transmission with 220 FT/LBS of torque, and quad box way “Y” axis support structure providing full way contact at full stroke unlike many competitors. Key differences between these two models include:

Contrast and Compare

Key Differences Between Models

Machine Dimensions

X-Axis Travel

Table Dimensions

Spindle Nose to Table

Max Table Load

VMC 6030B-II

166” x 138” x 132”

60”

61” x 30”

5-35/13-43”*

4,400 lbs

VMC 8030B-II

218” x 118” x 132”

80”

81.5” x 30”

5-35

4,840 lbs

The Details

Features and Specifications

VMC 6030B-II

  • Box Way Construction
  • Spindle Oil Cooler
  • 3 LED Work Lamps (2 Bar/1 Round)
  • Fully Enclosed
  • Spindle Air Blast
  • Automatic PDI Lubrication System
  • Operation Indication Lamp
  • Rigid Tapping
  • 3-Way Chip Augers
  • High Torque (22.5hp peak)
  • Chip Wash Down System
  • Remote MPG
  • Chip Conveyor
  • BT40
  • 4th Axis Ready
  • 5th Axis Ready
  • RTCP
  • FR-8,  FR-15 Rotary Table
  • FTR-8 Tilting Table
  • 30 position and 40 position
  • Coolant thru spindle
  • Very High Torque ( 30 hp peak )

OPTIONAL PROBING

  • Tool Pre-Setter (wired)
  • Tool Pre-Setter (wireless)
  • X, Y, Z Coordinate (wireless)

Travel

X-axis Travel (in.)

60

Y-axis Travel (in.)

32

Z-axis Travel (in.)

30

Spindle nose to table (in.)

5-35/13-43*

Spindle center to column (in.)

30.2

Table

Table Dimensions (in.)

61 x 30

T-Slot Dimensions (in.)

(5) 5.5 x .709 x 1.25

Max. Table Load (lbs.)

4400

Spindle

Spindle Type

CAT-40/BT-40**

Spindle Speed (RPM)

10,000/15,000**

Spindle Torque (ft. lbs.)

225

Spindle Motor (HP) Peak

22.5

Feed

Rapid Traverse Rate X,Y & Z (IPM)

787 / 787 / 590

Ballscrew Diameter X,Y & Z Axis (mm)

50

ATC

Tool Capacity

24/30*/40*

Tool Change Type

Dual Arm

Tool Change Time (sec.)

1.0 tool to tool

Max. Tool Weight (lbs.)

15

Max. Tool Diameter (in.) (with adjacent tool)

4.9 (3.1)

Max. Tool Length (in.)

13.8

Tool Selection Method

Random

Other

Machine dimensions L x W x H (in.)

166 x 138 x 132

W/Chip conveyor

220 x 118 x 132

Machine weight (lbs.)

32,400

• Specifications are subject to change without notice

*Optional

  • Backward compatible to 88HS & MP
  • Memory 4g
  • 2,500 blocks/sec look ahead
  • Networking and USB ports
  • High speed machining

VMC 8030B-II

  • Box Way Construction ( 4 Ways on 4-Axis )
  • Spindle Oil Cooler
  • 3 LED Work Lamps (2 Bar/1 Round)
  • Fully Enclosed
  • Spindle Air Blast
  • Automatic PDI Lubrication System
  • Operation Indication Lamp
  • Rigid Tapping
  • 3-Way Chip Augers
  • High Torque (22.5hp peak)
  • Chip Wash Down System
  • Remote MPG
  • Chip Conveyor
  • BT40
  • 4th Axis Ready
  • 5th Axis Ready
  • RTCP
  • FR-8,  FR-15 Rotary Table
  • FTR-8 Tilting Table
  • 30 Tool and 40 Tool DATC
  • Coolant thru spindle
  • Very High Torque ( 30 hp peak )

OPTIONAL PROBING

  • Tool Pre-Setter (wired)
  • Tool Pre-Setter (wireless)
  • X, Y, Z Coordinate (wireless)

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.

Travel

X-axis Travel (in.)

80

Y-axis Travel (in.)

32

Z-axis Travel (in.)

30

Spindle nose to table (in.)

5-35

Spindle center to column (in.)

30.2

Table

Table Dimensions (in.)

81.5 x 30

T-Slot Dimensions (in.)

(5) 5.5 x .709 x 1.25

Max. Table Load (lbs.)

4840

Spindle

Spindle Type

CAT-40/BT-40*

Spindle Speed (RPM)

10,000/15,000

Spindle Torque (ft. lbs.)

225

Spindle Motor (HP) Peak

22.5

Feed

Rapid Traverse Rate X,Y & Z (IPM)

787 / 787 / 590

Ballscrew Diameter X,Y & Z Axis (mm)

50

ATC

Tool Capacity

24/30*/40*

Tool Change Type

Dual Arm

Tool Change Time (sec.)

1.0 tool to tool

Max. Tool Weight (lbs.)

15

Max. Tool Diameter (in.) (with adjacent tool)

4.9 (3.1)

Max. Tool Length (in.)

13.8

Tool Selection Method

Random

Other

Machine dimensions L x W x H (in.)

218 x 118 x 132

W/Chip conveyor

272 x 118 x 132

Machine weight (lbs.)

34,600

• Specifications are subject to change without notice

*Optional

  • Backward compatible to 88HS & MP
  • Memory 4g
  • 2,500 blocks/sec look ahead
  • Networking and USB ports
  • High speed machining
