VMC 6032

Fadal VMC 6032
Cnc machining near me
  • Two spindle configurations
  • Quad box way “Y” axis support structure
  • Full way contact at full stroke

6032/8032 models can be configured with a CAT50 6,000 RPM spindle with a two speed transmission. Both models offer a 10,000 RPM CAT 40 dual belt transmission with 220 FT/LBS of torque, and quad box way “Y” axis support structure providing full way contact at full stroke unlike many competitors.

The Details

Features and Specifications

Cube

Machine Dimensions (in)

166 x 118 x 132

Table Dimensions (in.)

61×30

Max. Table Load (lbs.)

4,400

Machine Weight (lbs.)

32,400

  • Rigid Box Way Construction
  • Extremely Rigid Y-Axis Quad Ways
  • Dual Range / High Torque Spindle
  • 24 Tool Dual Arm Tool Changer
  • Spindle Oil Cooler
  • Rigid Taping
  • High Speed Machining
  • Bright LED Work Lamp & Light Tubes
  • Fully Enclosed
  • 4 x Chip Augers (3 w/ Optional Chip conveyor)
  • Spindle Air Blast
  • Automatic PDI Lubrication System
  • Dual Supported / Pre-Tensioned Ballscrews
  • Auto Lubricated Ballscrews & Thrust
  • Bearings Operation Indicator Lamp
  • Chip Wash Down System
  • 3-Stage Chip Separation
  • 2- Year /4,000 User-Hours Warranty*

*Whichever comes first

  • Chain Type Chip Conveyor
  • Very High Torque Spindle (VHT)
  • Coolant-Thru-Spindle (CTS)
  • Coolant-Thru-Spindle: Head Prep Only
  • 15,000 RPM Spindle: Greasepack
  • 15,000 RPM Spindle: Air/Oil
  • Hard Wired Tool Presetter
  • Wireless Touch Probe
  • Wireless Tool Presetter
  • Wireless Touch Probe/Tool Presetter
  • 30 Tool ATC
  • 40 Tool ATC
  • 4th & 5th Axis Prewire
  • 4th Axis Servo Disconnect (4 Axis Ready)
  • 4th/5th Axis Servo Disconnect (4+1 Axis Ready)
  • 4th/5th Axis Servo Disconnect (5 Axis Simultaneous)
  • FR-8D: 8″ Rotary Table (Req. 4th Axis Servo Disconnect)
  • FR-10D: 10″ Rotary Table (Req. 4th Axis Servo Disconnect)
  • FR-12D: 12″ Rotary Table (Req. 4th Axis Servo Disconnect)
  • FR-15D: 15″ Rotary Table (Req. 4th Axis Servo Disconnect)
  • Tailstock: FR-8D,10D,12D,15D (Manual Clamp w/Quill)
  • 3-Jaw Chuck with Flange: FR-8D,10D,12D,15D
  • Rotational Tool Center Point (RTCP)

Travel
X-axis Travel (in.) 60
Y-axis Travel (in.) 32
Z-axis Travel (in.) 30
Spindle Nose to Table (in.) 5-35
Spindle Center to Column (in.) 30.2
Table
Table Dimensions (in.) 61×30
T-Slot Dimensions (in.) (5) 5.5 x .709 x 1.25
Max. Table Load (lbs.) 4,400
Spindle
Spindle Type CAT-40/BT-40*
Spindle Speed (RPM) 10,000/15,000*
Spindle Torque (ft. lbs.) 220/300*
Spindle Motor (HP) Peak 22.5/30*
Feed
Rapid Traverse Rate X,Y & Z (IPM) 787 / 787 /590
Ballscrew Diameter X,Y & Z Axis (mm) 50
ATC
Tool Capacity 24 / 30* / 40*
Tool Change Time (sec.) 1.5 tool to tool
Tool Change Type Dual Arm
Max. Tool Weight (lbs.) 15
Max. Tool Diameter (in.) (with adjacent tool) 4.9 (3.1)
Max. Tool Length (in.) 13.8
Tool Selection Method Random
Other
Machine Dimensions L x W x H (in.) 166 x 118 x 132
W/ Chip Conveyor 220 x 118 x 132
Machine Weight (lbs.) 32,400
  • Specifications are subject to change without notice

*Optional

  • Backward Compatible: 88HS & MP
  • 15″ Color Monitor
  • Memory 4GB
  • 3,000 Blocks/Sec Look Ahead
  • Networking & USB Ports
  • High Speed Machining
  • Jog Away
  • Mirror Imaging
  • Mid-Program Start
  • Conversational Programming
  • 5 Axis Compatible
  • Coordinate Rotation & Scaling
