VMC 8032/50T

Fadal Engineering VMC 8032/50T
Cnc machining near me
  • 50 Taper, Geared Spindle
  • Heavy Box Way Construction W/ Quad Ways on Y-Axis
  • Wider Stance For Maximum Rigidity

This heavy-duty machine incorporates our dual range geared head with 425 FT/LBS of torque. Due to the robust construction, combined with the 50 Taper, geared spindle, this machine is ideal for the heavier cuts.

The Details

Features and Specifications

Cube

Machine Dimensions (in)

218 x 127 x 132

Table Dimensions (in.)

81.5 x 30

Max. Table Load (lbs.)

4,840

Machine Weight (lbs.)

38,600

  • Rigid Box Way Construction
  • Extremely Rigid Y-Axis Quad Ways
  • Dual Range / Geared 50 Taper Spindle
  • 32 Tool Dual Arm Tool Changer
  • Spindle Oil Cooler
  • Rigid Taping
  • High Speed Machining
  • Bright LED Work Lamp & Light Tubes
  • Fully Enclosed
  • 4 x Chip Augers (3 w/ Optional Chip conveyor)
  • Spindle Air Blast
  • Automatic PDI Lubrication System
  • Dual Supported / Pre-Tensioned Ballscrews
  • Auto Lubricated Ballscrews & Thrust
  • Bearings Operation Indicator Lamp
  • Chip Wash Down System
  • 3-Stage Chip Separation
  • 2- Year /4,000 User-Hours Warranty*

*Whichever comes first

  • Chain Type Chip Conveyor
  • Coolant-Thru-Spindle (CTS)
  • Hard Wired Tool Presetter
  • Wireless Touch Probe
  • Wireless Tool Presetter
  • Wireless Touch Probe/Tool Presetter
  • 40 Tool ATC
  • 4th & 5th Axis Prewire
  • 4th Axis Servo Disconnect (4 Axis Ready)
  • 4th/5th Axis Servo Disconnect (4+1 Axis Ready)
  • 4th/5th Axis Servo Disconnect (5 Axis Simultaneous)
  • FR-8D: 8″ Rotary Table (Req. 4th Axis Servo Disconnect)
  • FR-10D: 10″ Rotary Table (Req. 4th Axis Servo Disconnect)
  • FR-12D: 12″ Rotary Table (Req. 4th Axis Servo Disconnect)
  • FR-15D: 15″ Rotary Table (Req. 4th Axis Servo Disconnect)
  • Tailstock: FR-8D,10D,12D,15D (Manual Clamp w/Quill)
  • 3-Jaw Chuck with Flange: FR-8D,10D,12D,15D
  • Rotational Tool Center Point (RTCP)

Travel
X-axis Travel (in.) 80
Y-axis Travel (in.) 32
Z-axis Travel (in.) 30
Spindle Nose to Table (in.) 5-35
Spindle Center to Column (in.) 34.375
Table
Table Dimensions (in.) 81.5 x 30
T-Slot Dimensions (in.) (5) 5.5 x .709 x 1.25
Max. Table Load (lbs.) 4,840
Spindle
Spindle Type CAT-50/BT-50*
Spindle Speed (RPM) 6,000
Spindle Torque (ft. lbs.) 425
Spindle Motor (HP) Peak 45
Feed
Rapid Traverse Rate X,Y & Z (IPM) 787 / 787 /590
Ballscrew Diameter X,Y & Z Axis (mm) 50
ATC
Tool Capacity 32 / 40*
Tool Change Time (sec.) 2 (tool to tool)
Tool Change Type Dual Arm
Max. Tool Weight (lbs.) 35
Max. Tool Diameter (in.) (with adjacent tool) 4.9 (3.1)
Max. Tool Length (in.) 15.75
Tool Selection Method Random
Other
Machine Dimensions L x W x H (in.) 218 x 127 x 132
W/ Chip Conveyor 272 x 127 x 132
Machine Weight (lbs.) 38,600
  • Specifications are subject to change without notice

*Optional

  • Backward Compatible: 88HS & MP
  • 15″ Color Monitor
  • Memory 4GB
  • 3,000 Blocks/Sec Look Ahead
  • Networking & USB Ports
  • High Speed Machining
  • Jog Away
  • Mirror Imaging
  • Mid-Program Start
  • Conversational Programming
  • 5 Axis Compatible
  • Coordinate Rotation & Scaling
